American Truxx Goliath AT1917 Wheel – Matte Black w/ Milled Spokes

Product Description

The American Truxx Goliath AT1917 wheel in the Matte Black w/ Milled Spokes finish is available in 20x9, 20x10, 22x12, 24x14 with 7 bolt patterns (6x135, 6x139.7, 5x127, 5x139.7, 8x170, 8x165.1, 8x180). Each size, bolt pattern and offset combination below is its own part number from The Wheel Group, American Truxx's U.S. distributor.

Before you order: match the bolt pattern, center bore, offset and load rating to your vehicle. Load rating is per wheel. If you are not sure which fitment you need, email sales@offgridhorizon.com or call (302) 496-3554 with your year, make, model and tire size and we will confirm it with you.

Specifications

Part # Size (in) Bolt pattern Offset (mm) Backspace (in) Center bore (mm) Load rating (lbs) Weight (lbs)
AT1917-2937M 20x9 6x135 / 6x139.7 0.00 5.00 106.10 2,500
AT1917-2952M 20x9 5x127 / 5x139.7 0.00 5.00 87.10 2,500
AT1917-2970M 20x9 8x170 0.00 5.00 125.20 3,800
AT1917-2981M 20x9 8x165.1 0.00 5.00 125.20 3,800
AT1917-2978M 20x9 8x180 0.00 5.00 124.10 3,800
AT1917-2137M 20x10 6x135 / 6x139.7 -24.00 4.56 106.10 2,500
AT1917-2152M 20x10 5x127 / 5x139.7 -24.00 4.56 87.10 2,500
AT1917-2170M 20x10 8x170 -24.00 4.56 125.20 3,800
AT1917-2181M 20x10 8x165.1 -24.00 4.56 125.20 3,800
AT1917-2178M 20x10 8x180 -24.00 4.56 124.10 3,800
AT1917-22237M 22x12 6x135 / 6x139.7 -44.00 4.77 106.10 2,500
AT1917-22252M 22x12 5x127 / 5x139.7 -44.00 4.77 87.10 2,500
AT1917-22270M 22x12 8x170 -44.00 4.77 125.20 3,800
AT1917-22281M 22x12 8x165.1 -44.00 4.77 125.20 3,800
AT1917-24437M 24x14 6x135 / 6x139.7 -76.00 4.51 106.10 2,500
AT1917-24470M 24x14 8x170 -76.00 4.51 125.20 3,800
AT1917-24481M 24x14 8x165.1 -76.00 4.51 125.20 3,800
